结合波形互相关的双差定位方法在2008年汶川地震余震序列中的应用

吕鹏 丁志峰 朱露培

吕鹏 丁志峰 朱露培. 2011: 结合波形互相关的双差定位方法在2008年汶川地震余震序列中的应用. 地震学报, 33(4): 407-419.
引用本文: 吕鹏 丁志峰 朱露培. 2011: 结合波形互相关的双差定位方法在2008年汶川地震余震序列中的应用. 地震学报, 33(4): 407-419.
Luuml; Peng Ding Zhifeng Zhu Lupeicom sh advance. 2011: Application of double-difference relocation technique to aftershocks of 2008 Wenchuan earthquake using waveform cross-correlation. Acta Seismologica Sinica, 33(4): 407-419.
Citation: Luuml; Peng Ding Zhifeng Zhu Lupeicom sh advance. 2011: Application of double-difference relocation technique to aftershocks of 2008 Wenchuan earthquake using waveform cross-correlation. Acta Seismologica Sinica, 33(4): 407-419.

结合波形互相关的双差定位方法在2008年汶川地震余震序列中的应用

详细信息
  • 中图分类号: P315.3+1

Application of double-difference relocation technique to aftershocks of 2008 Wenchuan earthquake using waveform cross-correlation

  • 摘要: 选取了汶川地震主震后的2008年5月12日——2009年8月31日, 震级为3.0le;MSle;5.0的余震4240次.利用波形互相关方法得到其P波到时,用双差定位方法对其进行定位,最终得到了2441次重新定位的结果.统计定位误差(两倍标准偏差)在E-W方向为0.4 km,N-S方向为0.4 km,垂直方向为0.7 km.定位结果表明,汶川地震的余震深度集中在10——20 km,震中分布与龙门山中央断裂带的走向关系密切.沿龙门山断裂的地震分布具有明显的分段性,西南段呈水平带状分布,东北段接近垂直分布,且在北川附近存在深度突变.这与龙门山断裂的地震在西南段多表现为逆冲,东北段多表现为走滑的现象相吻合.在深度剖面上地震的空间分布存在分立的特征,通过对比前人在此地区浅层的地震剖面资料, 发现地震空间分布与已探知的浅部断层有较好的对应关系.
    Abstract: We collected seismic records of 4240 3.0le;MSle;5.0 aftershocks of the 2008 Wenchuan earthquake for the period of 12 May 2008 to 31 August 2009. By using waveform cross correlation and double-difference method, 2441 events of them were relocated. The errors are 0.4 km in horizontal and 0.7 km in vertical direction, respectively. It is found that the depth of aftershocks concentrate in 10mdash;20 km range, and the epicenters distribute close to the strike of the central Longmenshan fault. The aftershock epicenters spread in horizontal belt for southwestern section of the aftershock zone, and in vertical belt for northeastern section. The aftershock depth abruptly change from 20 km to 10 km near Beichuan. This implies that the spatial distribution of aftershocks show different characteristics along Longmenshan fault, confirming the previous viewpoint that the fault is thrust in SW, while strike-slip in NE. Comparison of the aftershock relocation result with the existing shallow seismic exploration profiles reveals that the aftershock belts well match the known shallow geological active faults.
  • 本目录中的地震参数来自“中国地震台站观测报告”(简称“月报”). 其中, 国内及邻区给出M≥4.7的事件, 全球给出M≥6.0的事件. “月报”由中国地震台网中心按月做出.

    本目录中的发震时刻采用协调世界时(UTC); 为了方便中国读者, 也给出北京时(BTC). 震中位置除给出经纬度外, 还给出参考地区名, 它仅用作查阅参考, 不包含任何政治意义; 还给出测定震源位置的台数(n)和标准偏差(SD).

    面波震级MS是用中周期宽频带SK地震仪记录, 采用北京台1965年面波震级公式MS=lg(AH/T)+1.66 lg(Δ)+3.5 (1°<Δ<130°)求得. AH是两水平分向最大面波位移的矢量合成位移. MS7是对763长周期地震仪记录, 采用国际上推荐的面波震级公式MS7=lg(AV/T)+1.66 lg(Δ)+3.3 (20°<Δ<160°)求得. AV是垂直向面波最大地动位移. mb是短周期体波震级, ML是近震震级, 为避免混乱, 震级之间一律不换算.

    表  1  中国及邻区地震目录(2015年9—10月, M≥4.7)
    Table  1.  Catalog of earthquakes within and near China (September--October, 2015, M≥4.7)
    编号 发 震 时 刻 地 理 坐 标 深度/km 震级 标准偏差(SD) 使用台数 (n) 地 区
    UTC BTC 日-时 纬度/°N 经度/°E M S M S7 ML mb
    月-日 时:分:秒
    1 09-0113:24:44.801-21 23.93121.54 105.25.15.24.72.3 96台湾岛
    2 0117:34:06.802-01 24.06122.41 214.74.64.44.42.0 76台湾岛
    31307:51:10.813-15 45.08 91.52 74.74.35.04.62.2 69新疆自治区北部
    41519:37:33.216-03 24.35121.90 105.65.55.75.01.6 98台湾岛
    51611:10:07.716-19 35.46 78.47 84.54.24.94.62.2 66克什米尔东部
    61613:08:57.116-21 24.25121.90 105.35.25.44.91.6101台湾岛
    710-1210:04:14.712-18 34.36 98.20 105.35.15.14.92.6 92青海省
    81211:14:46.812-19 22.47121.48 124.74.44.94.51.7 84台湾地区
    91902:17:36.119-10 24.93122.00 105.55.35.64.91.9 97台湾岛
    101905:42:13.119-13 24.97121.79 104.74.54.54.42.2 71台湾岛
    111907:20:16.719-15 24.98121.99 104.74.54.64.41.9 73台湾岛
    122105:58:21.021-13 44.68124.16 104.54.35.14.32.0 50中国东北部
    132618:11:23.827-02 30.17 98.01 64.64.44.44.72.3 58西藏自治区
    142820:12:08.529-04 27.55100.30 104.84.64.54.52.5 78云南省
    153011:26:39.430-19 25.04 99.44 105.04.75.14.72.5 84缅甸—中国边境地区
    下载: 导出CSV
    | 显示表格
    表  2  全球地震目录(2015年9—10月, M≥6.0)
    Table  2.  Catalog of earthquakes all over the world (September--October, 2015, M≥6.0)
    编号 发 震 时 刻 地 理 坐 标 深度/km 震级 标准偏差(SD) 使用台数 (n) 地 区
    UTC BTC 日-时 纬度/° 经度/° MS MS7 mb
    月-日 时:分:秒
    1 09-0115:25:06.601-23 31.19N141.88E 206.15.95.31.6 67本州以南地区
    2 0709:13:56.607-17 33.07S177.99W 296.25.95.41.7 74克马德克群岛以南地区
    3 0714:06:24.707-22 32.98S177.83W 126.05.75.31.9 84克马德克群岛以南地区
    4 0808:03:55.008-16 14.70N 93.90W 106.05.71.4 56墨西哥恰帕斯海岸近海
    51010:26:42.310-18 52.46N169.64W 186.05.95.61.1 98福克斯群岛
    61308:14:10.013-16 25.14N109.38W 106.86.75.52.6 64加利福尼亚湾
    71607:40:57.516-15 1.89N126.42E 506.16.05.71.3101马鲁古海峡
    81614:03:21.716-22 6.03S151.48E 206.05.85.31.6102新不列颠地区
    91622:54:31.517-06 31.59S 71.62W 208.38.31.3 80中智利海岸近海
    101623:18:40.317-07 31.45S 71.20W 306.86.82.3 91中智利海岸近海
    111701:41:10.217-09 31.10S 71.45W 406.46.41.4 88中智利海岸近海
    121703:55:17.517-11 31.10S 71.35W 406.56.51.9 67中智利海岸近海
    131704:10:27.717-12 31.55S 71.70W 306.96.92.8 94中智利海岸近海
    141809:10:50.018-17 32.25S 72.10W 256.36.32.3 93中智利海岸近海
    151815:59:42.518-23 15.30N 46.00W 106.26.02.5 53北大西洋海岭
    161912:52:19.719-20 32.25S 71.80W 106.46.41.4 99中智利海岸近海
    171913:08:56.519-21 30.89S 72.68W 106.36.03.1 37中智利海岸近海
    182105:39:32.621-13 31.55S 71.70W 206.26.11.2 92中智利海岸近海
    192117:39:57.422-01 31.65S 71.60W 206.86.81.3 95中智利海岸近海
    202415:53:28.824-23 0.55S131.25E 306.56.25.91.3 97西伊里安地区
    212415:56:53.824-23 9.81S160.70E 186.46.25.9 0.7 71所罗门群岛
    222602:51:15.726-10 30.80S 71.30W 306.36.31.2102中智利海岸近海
    2310-1100:58:29.011-08 54.60S135.80W 106.05.83.0 40南太平洋山系
    241405:43:04.014-13 48.88N156.25E 106.36.35.61.3 99千岛群岛
    251711:33:08.017-19 24.89S 64.31W 106.05.92.2 74阿根廷萨尔塔省
    262021:52:0.021-05 14.82S167.32E 1306.21.3 82瓦努阿图(新赫布里底)
    272609:09:31.226-17 36.59N 70.79E 2076.1 0.9 94兴都库什地区
    下载: 导出CSV
    | 显示表格
